PTN78000HAST
RoHS
RoHS compliant
RoHS compliantPackage 5-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
REG SW WIDE-VIN 1.5A ADJ HRZ SMD
PDF
/
Inventory: 9711
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 5-SMD Module
Surface Mount NO
Number of Pins 5
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series PTN78000H
Size / Dimension 0.75Lx0.50W x 0.36 H 19.1mmx12.7mmx9.1mm
JESD-609 Code e0
Feature OCP, OTP, UVLO
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 7
ECCN Code EAR99
Type Non-Isolated PoL Module
Terminal Finish TIN LEAD
Applications ITE (Commercial)
Max Power Dissipation 33W
Technology HYBRID
Terminal Position DUAL
Terminal Form UNSPECIFIED
Number of Functions 1
Base Part Number PTN78000
Pin Count 5
JESD-30 Code R-XDMA-X7
Number of Outputs 1
Efficiency 94%
Voltage - Input (Max) 36V
Output Voltage 22V
Max Output Current 1.5A
Voltage - Output 1 11.85V~22V
Voltage - Input (Min) 15V
Output Current 1.5A
Output Power 22.5W
Max Output Voltage 22V
Current - Output 1 1.5A
Min Output Voltage 11.85V
Dimensions
Height 9.144mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
Alternative Model
