PT6982A
RoHS
RoHS compliant
RoHS compliantPackage 23-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
REGULATOR 3.3/2.5V 12VIN HORZ
PDF
/
Inventory: 8777
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 10.922mm
Technical
Switching Frequency-Max 600kHz
Switcher Configuration SINGLE
Control Mode VOLTAGE-MODE
Voltage - Output 2 2.5V
Current - Output (Max) 10.5A 2.25A
Input Voltage-Nom 12V
Voltage - Input (Min) 10.8V
Max Output Current 2.25A
Output Voltage 3.3V
Voltage - Input (Max) 13.2V
Efficiency 84%
Qualification Status Not Qualified
Number of Outputs 2
Pin Count 23
Base Part Number PT6982
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) 215
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 40.3W
Power Rating 34W
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 23
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension 2.58Lx1.19W x 0.43 H 65.5mmx30.2mmx10.9mm
Series Excalibur? PT6980
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Package / Case 23-SIP Module
Mounting Type Through Hole, Right Angle
Mount Through Hole
