IMM0105S3V3

XP Power
RoHS
RoHS RoHS compliant
Package 7-SIP Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description DC-DC CONV, 1W, MEDICAL APPROVAL
PDF
/
Buying Options
Total Price: USD $19.1
Unit Price: USD $19.1012
≥1 USD $19.1012
≥10 USD $18.02
≥100 USD $17
≥500 USD $16.03774
≥1000 USD $15.12994
Inventory: 4694
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC No SVHC

Dimensions

Height 11.176mm

Technical

Min Input Voltage (DC) 4.5V
Max Input Voltage (DC) 9V
Max Output Power 1W
Current - Output 1 303mA
Control Features Enable, Active Low
Output Power 1W
Trim/Adjustable Output NO
Input Voltage-Nom 5V
Voltage - Output 1 3.3V
Max Output Current 303mA
Output Voltage 3.3V
Voltage - Input (Max) 9V
Voltage - Isolation 1.5kV
Efficiency 81%
Number of Outputs 1
JESD-30 Code R-XSMA-P6
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 9.2mm
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 1W
Applications Medical
Type Isolated Module
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Remote On/Off, SCP
Size / Dimension 0.77Lx0.36W x 0.44 H 19.5mmx9.2mmx11.1mm
Series IMM01 (1W)
Published 2016
Packaging Tube
Operating Temperature -20°C~100°C

Physical

Package / Case 7-SIP Module, 5 Leads
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Factory Lead Time 10 Weeks
