PT6728N
RoHS
RoHS compliant
RoHS compliantPackage 17-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
REGULATOR 1.5V 14A CU CASE VERT
PDF
/
Inventory: 5131
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 12.7mm
Length 65.28mm
Technical
Isolation Non-Isolated
Switching Frequency-Max 400kHz
Switcher Configuration SINGLE
Control Mode VOLTAGE-MODE
Output Current 14A
Input Voltage-Nom 12V
Voltage - Input (Min) 10.8V
Max Output Current 14A
Output Voltage 1.5V
Voltage - Input (Max) 13.2V
Efficiency 81%
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 17
Base Part Number PT6728
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 12.7mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 21W
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 17
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series Excalibur? PT6725
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Number of Pins 17
Package / Case 17-SIP Module
Mounting Type Through Hole
Mount Through Hole
