ISL2412A

XP Power
RoHS
RoHS RoHS compliant
Package 16-SMD Module, 6 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description XP POWER ISL2412A Isolated Board Mount DC/DC Converter, Surface Mount DIP, Fixed, SMD, 1.5 W, 12 V, 125 mA
PDF
/
Buying Options
Total Price: USD $21.91
Unit Price: USD $21.9102
≥1 USD $21.9102
≥10 USD $20.67
≥100 USD $19.5
≥500 USD $18.39623
≥1000 USD $17.35493
Inventory: 7559
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC Unknown

Dimensions

Height 7.874mm

Technical

Min Input Voltage (DC) 9V
Max Input Voltage (DC) 36V
Nominal Output Voltage 12V
Max Output Power 1.5W
Current - Output 1 125mA
Output Power 1.5W
Output Current 125mA
Trim/Adjustable Output NO
Input Voltage-Nom 24V
Max Output Current 125mA
Output Voltage 12V
Voltage - Input (Max) 36V
Voltage - Isolation 1.5kV
Efficiency 79%
Number of Outputs 1
JESD-30 Code R-XDMA-G6
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 23.86mm
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 2W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature SCP
Size / Dimension 0.94Lx0.54W x 0.31 H 23.9mmx13.7mmx8.0mm
Series ISL (1.5W)
Published 2013
Packaging Tube
Operating Temperature -40°C~85°C

Physical

Package / Case 16-SMD Module, 6 Leads
Mounting Type Surface Mount
Mount PCB, Surface Mount

Supply Chain

Factory Lead Time 11 Weeks
