PT6674P image
Favorite
PT6674P image
Favorite
RoHS
RoHS RoHS compliant
Package 14-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description Isolated DC/DC Converters 12Vout 5V-Input 24W Boost ISR
PDF
/
Buying Options
Total Price: USD $31.55
Unit Price: USD $31.548953
≥1 USD $31.548953
≥10 USD $29.763163
≥100 USD $28.078458
≥500 USD $26.489112
≥1000 USD $24.98973
Inventory: 1165
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Width 10.7mm
Length 43.43mm

Technical

Switching Frequency-Max 300kHz
Control Mode VOLTAGE-MODE
Topology Boost
Output Power 20W
Output Current 2A
Input Voltage-Nom 5V
Voltage - Input (Min) 4.5V
Max Output Current 2A
Output Voltage 12V
Voltage - Input (Max) 5.5V
Efficiency 86%
Number of Outputs 1
Pin Count 14
Base Part Number PT6674
Number of Functions 1
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 24W
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series PT6670
Packaging Tray
Operating Temperature -40°C~85°C

Physical

Weight 14g
Number of Pins 14
Package / Case 14-SIP Module
Mounting Type Through Hole
Mount Through Hole
