PT6626B
RoHS
/
Package 14-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 9V 54W
PDF
/
Inventory: 1816
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Height 10.668mm
Technical
Switching Frequency-Max 750kHz
Switcher Configuration SINGLE
Control Mode VOLTAGE-MODE
Input Voltage-Nom 12V
Voltage - Input (Min) 12V
Voltage - Output 1 9V
Max Output Current 6A
Voltage - Input (Max) 16V
Efficiency 92%
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 14
Base Part Number PT6626
Terminal Pitch 2.54mm
Number of Functions 1
Terminal Form GULL WING
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 54W
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Feature Remote On/Off, OTP
Size / Dimension 2.36Lx1.22W x 0.42 H 59.9mmx31.0mmx10.7mm
Series PT6620
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Package / Case 14-SMD Module
Mounting Type Surface Mount
Mount Surface Mount
