PT6603L
RoHS
RoHS compliant
RoHS compliantPackage 14-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC/DC Converters 2.5Vout 9A 5V-Inp Adj ISR
PDF
/
Buying Options
Total Price: USD $23.96
Unit Price: USD $23.9624
≥1 USD $23.9624
Inventory: 111
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 14-SMD Module
Number of Pins 16
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Series PT6600
Size / Dimension 1.71Lx1.22W x 0.42 H 43.4mmx31.0mmx10.7mm
Feature Remote On/Off, OTP
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
ECCN Code EAR99
Type Non-Isolated PoL Module
Applications ITE (Commercial)
Additional Feature 3.3V INPUT BUS CAPABLE
Subcategory Switching Regulator or Controllers
Max Power Dissipation 18W
Technology HYBRID
Terminal Position SINGLE
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 2.54mm
Depth 30.98mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number PT6603
Pin Count 14
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 76%
Voltage - Input (Max) 6V
Output Voltage 2.5V
Max Output Current 9A
Voltage - Input (Min) 4.5V
Input Voltage-Nom 5V
Output Current 9A
Control Mode VOLTAGE-MODE
Switcher Configuration SINGLE
Switching Frequency-Max 725kHz
Isolation Non-Isolated
Dimensions
Height 10.668mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
