PT5047LT
RoHS
RoHS compliant
RoHS compliantPackage 3-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
REGLTR 18V0.66A 3PIN HS SMD
PDF
/
Inventory: 4195
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 9.65mm
Length 25.4mm
Height 25.9mm
Technical
Switching Frequency-Max 950kHz
Topology Boost
Input Voltage-Nom 5V
Voltage - Input (Min) 4.75V
Max Output Current 600mA
Output Voltage 18V
Voltage - Input (Max) 14V
Efficiency 85%
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 3
Base Part Number PT5047
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) 215
Terminal Form GULL WING
Terminal Position DUAL
Max Power Dissipation 10.8W
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series PT5040
Packaging Tape & Reel (TR)
Operating Temperature -20°C~85°C
Physical
Number of Pins 3
Package / Case 3-SMD Module
Mounting Type Surface Mount
Mount Surface Mount
