PT4413A
RoHS
RoHS compliant
RoHS compliantPackage 21-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 3.4-5.7V 100W
PDF
/
Buying Options
Total Price: USD $119.92
Unit Price: USD $119.920276
≥1 USD $119.920276
≥10 USD $113.132335
≥100 USD $106.728622
≥500 USD $100.687374
≥1000 USD $94.98809
Inventory: 948
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole, Right Angle
Package / Case 21-SIP Module
Number of Pins 21
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Series Excalibur? PT4410 (100W)
Feature UVLO
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Subcategory Other Analog ICs
Max Power Dissipation 114W
Technology HYBRID
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 2.54mm
Depth 36.83mm
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number PT4413
JESD-30 Code R-MSMA-T20
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 92%
Isolation Isolated
Output Power 100W
Output Current 30A
Trim/Adjustable Output YES
Input Voltage-Nom 48V
Voltage - Input (Min) 36V
Voltage - Output 1 3.4V~5.7V
Max Output Current 20A
Output Voltage 5.7V
Voltage - Input (Max) 75V
Voltage - Isolation 1.5kV
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Dimensions
Width 37.1mm
Length 65.28mm
