PT3343A
RoHS
RoHS compliant
RoHS compliantPackage 19-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
Module DC-DC 24VIN 1-OUT 12V 2.5A 30W 19-Pin SIP Module
PDF
/
Buying Options
Total Price: USD $214.5
Unit Price: USD $214.504917
≥1 USD $214.504917
≥10 USD $207.451565
≥25 USD $206.0095
≥50 USD $204.577457
≥100 USD $200.369695
≥500 USD $186.044283
Inventory: 8674
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 32.3mm
Length 76.96mm
Technical
Isolation Isolated
Output Power 30W
Output Current 2.5A
Trim/Adjustable Output YES
Input Voltage-Nom 24V
Voltage - Input (Min) 18V
Voltage - Output 1 12V
Max Output Current 2.5A
Output Voltage 12V
Voltage - Input (Max) 60V
Voltage - Isolation 1.5kV
Efficiency 86%
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 19
Base Part Number PT3343
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 32.25mm
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 30W
Power Rating 30W
Subcategory Other Analog ICs
Additional Feature UNDERVOLTAGE LOCKOUT
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 19
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Series PT3340 (30W)
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Number of Pins 19
Package / Case 19-SIP Module
Mounting Type Through Hole, Right Angle
Mount Through Hole
