DCR012405P
RoHS
RoHS compliant
RoHS compliantPackage 18-DIP Module, 10 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
IC REG ISOLATED 5V 0.2A 10DIP
PDF
/
Buying Options
Total Price: USD $15.38
Unit Price: USD $15.3824
≥1 USD $15.3824
≥10 USD $15.26272
≥100 USD $15.14524
≥500 USD $14.19858
≥1000 USD $13.015376
≥3000 USD $12.778718
Inventory: 338
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Mounting Type Through Hole
Package / Case 18-DIP Module, 10 Leads
Surface Mount NO
Number of Pins 10
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Series DCR01 (1W)
Size / Dimension 0.90Lx0.28W x 0.21 H 22.9mmx7.1mmx5.3mm
JESD-609 Code e4
Feature Remote On/Off, OTP, SCP
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 10
ECCN Code EAR99
Type Isolated Module
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Applications ITE (Commercial)
Subcategory Other Analog ICs
Power Rating 1W
Max Power Dissipation 1W
Technology HYBRID
Terminal Position DUAL
Number of Functions 1
Terminal Pitch 2.54mm
Base Part Number DCR012405
Number of Outputs 1
Voltage - Isolation 1kV
Voltage - Input (Max) 26.4V
Output Voltage 5V
Output Type Adjustable, Fixed
Max Output Current 200mA
Voltage - Input (Min) 21.6V
Input Voltage-Nom 24V
Trim/Adjustable Output NO
Output Current 200mA
Quiescent Current 15mA
Output Power 1W
Control Features Enable, Active High
Max Output Voltage 5.1V
Protections THERMAL
Control Mode VOLTAGE
Current - Output 1 200mA
Min Output Voltage 4.9V
Max Output Power 1W
Nominal Output Voltage 3.3V
Switching Frequency 880kHz
Dimensions
Height 4.95mm
Length 22.86mm
Thickness 3.94mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
