78HT265HC
RoHS
RoHS compliant
RoHS compliantPackage 3-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
REGULATOR 6.5V HORIZONTAL
PDF
/
Buying Options
Total Price: USD $81.68
Unit Price: USD $81.676864
≥1 USD $81.676864
≥10 USD $77.053648
≥100 USD $72.692113
≥500 USD $68.577471
≥1000 USD $64.695724
Inventory: 1408
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole, Right Angle
Package / Case 3-SIP Module
Number of Pins 3
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Series 78HT200
Size / Dimension 0.94Lx0.90W x 0.31 H 23.9mmx22.9mmx7.9mm
Feature OTP, SCP
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Type Non-Isolated PoL Module
Applications ITE (Commercial)
Max Power Dissipation 13W
Terminal Position SINGLE
Number of Functions 1
Depth 22.86mm
Base Part Number 78HT265
Pin Count 3
Number of Outputs 1
Efficiency 82%
Voltage - Input (Max) 28V
Output Voltage 6.5V
Max Output Current 2A
Voltage - Input (Min) 8.5V
Input Voltage-Nom 9V
Output Current 2A
Switcher Configuration BUCK
Switching Frequency-Max 800kHz
Dimensions
Height 7.874mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
