NDY4812C
RoHS
/
Package 24-DIP Module, 8 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
Isolated DC/DC Converters 3W 36-72VIN 12V OUT Single Output
PDF
/
Inventory: 1186
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Length 32.26mm
Height 6.858mm
Technical
Isolation Isolated
Nominal Input Voltage 48V
Total Power Output-Max 3W
Current - Output 1 250mA
Output Power 3W
Output Current 250mA
Trim/Adjustable Output NO
Input Voltage-Nom 48V
Voltage - Input (Min) 36V
Max Output Current 250mA
Output Voltage 12V
Voltage - Input (Max) 72V
Voltage - Isolation 1kV
Efficiency 81%
Number of Outputs 1
JESD-30 Code R-XDMA-T24
Pin Count 24
Depth 14.66mm
Terminal Pitch 2.54mm
Number of Functions 1
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 3W
Power Rating 3W
Subcategory Other Analog ICs
Applications ITE (Commercial)
Terminal Finish Bright Tin (Sn)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Size / Dimension 1.27Lx0.58W x 0.27 H 32.3mmx14.7mmx6.9mm
Series NDY (3W)
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Number of Pins 8
Package / Case 24-DIP Module, 8 Leads
Mounting Type Through Hole
Mount Through Hole
