CC15-4805SFP-E
RoHS
/
Package 20-DIP Module, 17 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 15W 48V 5V 3A PCB
PDF
/
Inventory: 9311
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Series CC-P-E (15W)
Size / Dimension 1.51Lx1.17W x 0.27 H 38.4mmx29.6mmx6.8mm
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 17
ECCN Code EAR99
Type Isolated Module
Terminal Finish Tin (Sn) - with Nickel (Ni) barrier
Applications ITE (Commercial)
Power Rating 15W
Max Power Dissipation 15W
Technology HYBRID
Terminal Position DUAL
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Depth 29.6mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Outputs 1
Efficiency 89%
Voltage - Isolation 1kV
Voltage - Input (Max) 76V
Output Voltage 5V
Max Output Current 3A
Input Voltage-Nom 48V
Trim/Adjustable Output NO
Output Current 3A
Output Power 15W
Control Features Enable, Active Low
Current - Output 1 3A
Nominal Input Voltage 48V
Max Output Power 15W
Published 2009
Packaging Tray
Operating Temperature -40°C~85°C
Nominal Output Voltage 5V
Max Input Voltage (DC) 76V
Min Input Voltage (DC) 36V
Physical
Number of Pins 17
Package / Case 20-DIP Module, 17 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status OBSOLETE (Last Updated: 2 months ago)
Factory Lead Time 14 Weeks
Dimensions
Height 6.858mm
Length 38.4mm
Compliance
REACH SVHC Unknown
RoHS Status RoHS Compliant
