RS-123.3S/H3
RoHS
RoHS compliant
RoHS compliantPackage 8-SIP Module, 7 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 2W 9-18VIN 3.3VOUT
PDF
/
Inventory: 1140
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 8-SIP Module, 7 Leads
Weight 4.7g
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Series ECONOLINE RS (2W)
Size / Dimension 0.86Lx0.36W x 0.44 H 21.8mmx9.2mmx11.1mm
Feature Remote On/Off, SCP
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 7
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial), Medical
Max Power Dissipation 2W
Technology HYBRID
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 2.54mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 8/7
JESD-30 Code R-XSMA-T7
Number of Outputs 1
Efficiency 69%
Voltage - Isolation 3kV
Voltage - Input (Max) 18V
Output Voltage 3.3V
Max Output Current 500mA
Voltage - Input (Min) 9V
Input Voltage-Nom 12V
Trim/Adjustable Output NO
Output Current 500mA
Output Power 2W
Control Features Enable, Active Low
Max Output Voltage 3.3V
Nominal Input Voltage 12V
Dimensions
Height 11.1mm
Width 9.2mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
