RP40-4812DGW
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 40W DUAL +/-12V OUT
PDF
/
Buying Options
Total Price: USD $104.42
Unit Price: USD $104.4208
≥1 USD $104.4208
≥10 USD $98.87856
≥100 USD $98.08832
≥500 USD $91.759712
≥1000 USD $88.595584
≥3000 USD $84.16584
Inventory: 91
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount PCB, Through Hole
Mounting Type Through Hole
Package / Case 8-DIP Module
Number of Pins 8
Weight 60g
Technical
Operating Temperature -40°C~95°C
Packaging Tube
Series POWERLINE RP40-GW (40W)
Size / Dimension 2.00Lx2.00W x 0.40 H 50.8mmx50.8mmx10.2mm
Feature Remote On/Off, OCP, OTP, OVP, SCP, UVLO
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Additional Feature HGT NOM
Power Rating 40W
Max Power Dissipation 40W
Technology HYBRID
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Depth 50.8mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 8
Number of Outputs 2
Efficiency 86%
Voltage - Isolation 1.6kV
Output Voltage 12V
Max Output Current 1.67A
Input Voltage-Nom 48V
Trim/Adjustable Output YES
Current - Output (Max) 1.67A 1.67A
Output Current 1.667A
Output Power 40W
Control Features Enable, Active High
Max Output Voltage 13.2V
Current - Output 1 1.667A
Nominal Input Voltage 48V
Max Output Power 40W
Isolation Isolated
Nominal Output Voltage -12V
Current - Output 2 -1.667A
Max Input Voltage (DC) 75V
Min Input Voltage (DC) 18V
Dimensions
Height 10.2mm
Length 51.3mm
Width 51.3mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Alternative Model
