RP15-4812DF-HC
RoHS
RoHS compliant
RoHS compliantPackage 6-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 15W 36-75VIN +/-12V
PDF
/
Inventory: 9834
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 6-DIP Module
Weight 37.9g
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Series POWERLINE RP15-F (15W)
Size / Dimension 2.00Lx1.00W x 0.40 H 50.8mmx25.4mmx10.2mm
Feature OCP, OVP, SCP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Subcategory Other Analog ICs
Max Power Dissipation 15W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Number of Functions 1
JESD-30 Code R-XDMA-P5
Number of Outputs 2
Qualification Status Not Qualified
Efficiency 88%
Voltage - Isolation 1.6kV
Voltage - Input (Max) 75V
Output Voltage 12V
Max Output Current 625mA
Voltage - Input (Min) 36V
Input Voltage-Nom 48V
Trim/Adjustable Output NO
Current - Output (Max) 625mA 625mA
Output Current 625mA
Output Power 15W
Max Output Voltage 12V
Voltage - Output 2 -12V
Nominal Input Voltage 48V
Dimensions
Height 16.8mm
Length 50mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
