RP15-2405DF
RoHS
RoHS compliant
RoHS compliantPackage 6-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 15W 18-36VIN +/-05V
PDF
/
Inventory: 1354
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Length 50.8mm
Height 10.2mm
Technical
Isolation Isolated
Nominal Input Voltage 24V
Voltage - Output 2 -5V
Max Output Voltage 5V
Output Power 15W
Output Current 1.5A
Current - Output (Max) 1.5A 1.5A
Trim/Adjustable Output NO
Input Voltage-Nom 24V
Voltage - Input (Min) 18V
Max Output Current 1.5A
Output Voltage 5V
Voltage - Input (Max) 36V
Voltage - Isolation 1.6kV
Efficiency 84%
Qualification Status Not Qualified
Number of Outputs 2
JESD-30 Code R-XDMA-P5
Depth 25.4mm
Number of Functions 1
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 15W
Subcategory Other Analog ICs
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature OCP, OVP, SCP
Size / Dimension 2.00Lx1.00W x 0.40 H 50.8mmx25.4mmx10.2mm
Series POWERLINE RP15-F (15W)
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Weight 27g
Number of Pins 6
Package / Case 6-DIP Module
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
