RP10-4805DEW/P
RoHS
RoHS compliant
RoHS compliantPackage 6-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 10W 18-75VIN +/-05V
PDF
/
Inventory: 4610
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 6-DIP Module
Weight 27g
Technical
Operating Temperature -25°C~85°C
Packaging Tube
Series POWERLINE RP10-EW (10W)
Size / Dimension 2.00Lx1.00W x 0.40 H 50.8mmx25.4mmx10.2mm
Feature Remote On/Off, OCP, OVP, SCP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Subcategory Other Analog ICs
Max Power Dissipation 10W
Technology HYBRID
Terminal Position DUAL
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-XDMA-T6
Number of Outputs 2
Qualification Status Not Qualified
Efficiency 81%
Voltage - Isolation 1.6kV
Voltage - Input (Max) 75V
Output Voltage 5V
Max Output Current 1A
Voltage - Input (Min) 18V
Input Voltage-Nom 48V
Trim/Adjustable Output NO
Current - Output (Max) 1A 1A
Output Current 1A
Output Power 10W
Control Features Enable, Active High
Max Output Voltage 5V
Voltage - Output 2 -5V
Nominal Input Voltage 48V
Dimensions
Height 10.2mm
Length 50.8mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
