RP10-2415DEW/N/M2
RoHS
RoHS compliant
RoHS compliantPackage 6-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 10W 9-36VIN +/-15VOUT
PDF
/
Buying Options
Total Price: USD $67.39
Unit Price: USD $67.3904
≥1 USD $67.3904
≥10 USD $64.8208
≥100 USD $64.30952
≥500 USD $62.268096
≥1000 USD $59.205696
≥3000 USD $55.122496
Inventory: 55
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Length 50.8mm
Height 10.2mm
Technical
Nominal Input Voltage 24V
Voltage - Output 2 -15V
Max Output Voltage 15V
Control Features Enable, Active Low
Output Power 10W
Output Current 333mA
Current - Output (Max) 333mA 333mA
Trim/Adjustable Output NO
Input Voltage-Nom 24V
Voltage - Input (Min) 9V
Max Output Current 333mA
Output Voltage 15V
Voltage - Input (Max) 36V
Voltage - Isolation 1.6kV
Efficiency 80%
Number of Outputs 2
JESD-30 Code R-XDMA-T6
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 10W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Remote On/Off, OCP, OVP, SCP
Size / Dimension 2.00Lx1.00W x 0.40 H 50.8mmx25.4mmx10.2mm
Series POWERLINE RP10-EW (10W)
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Weight 27g
Package / Case 6-DIP Module
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
