RO-3.309S/HP
RoHS
RoHS compliant
RoHS compliantPackage 4-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 9V 1W
PDF
/
Buying Options
Total Price: USD $6.31
Unit Price: USD $6.31238
≥1 USD $6.31238
≥10 USD $5.95508
≥100 USD $5.618
≥500 USD $5.3
≥1000 USD $5
≥3000 USD $4.71698
Inventory: 6753
Minimum: 1
-
+
Technical Details
Technical
Terminal Pitch 2.54mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 4
JESD-30 Code R-XSMA-P4
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 80%
Voltage - Isolation 2kV
Voltage - Input (Max) 3.6V
Output Voltage 9V
Max Output Current 111mA
Voltage - Input (Min) 3V
Input Voltage-Nom 3.3V
Trim/Adjustable Output NO
Output Current 111mA
Output Power 1W
Max Output Voltage 9V
Total Power Output-Max 1W
Nominal Input Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 1W
Subcategory Other Analog ICs
Applications ITE (Commercial), Medical
Type Isolated Module
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature SCP
Size / Dimension 0.45Lx0.24W x 0.39 H 11.5mmx6.0mmx10.0mm
Series ECONOLINE RO (1W)
Packaging Tube
Operating Temperature -40°C~85°C
Dimensions
Height 10mm
Width 6mm
Compliance
RoHS Status ROHS3 Compliant
Physical
Weight 1.4g
Package / Case 4-SIP Module
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 9 Weeks
