RN-2412S/H
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP Module, 4 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 1.25W 24VIN 12VOUT
PDF
/
Buying Options
Total Price: USD $7.57
Unit Price: USD $7.57486
≥1 USD $7.57486
≥10 USD $7.1461
≥100 USD $6.7416
≥500 USD $6.36
≥1000 USD $6
≥3000 USD $5.66038
Inventory: 2125
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 8-DIP Module, 4 Leads
Weight 1.9g
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Series ECONOLINE RN (1.25W)
Size / Dimension 0.50Lx0.40W x 0.30 H 12.8mmx10.1mmx7.6mm
Feature SCP
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 4
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Subcategory Other Analog ICs
Max Power Dissipation 1.25W
Terminal Position DUAL
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Pitch 2.54mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PDIP-T4
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 82%
Voltage - Isolation 2kV
Voltage - Input (Max) 26.4V
Output Voltage 12V
Max Output Current 104mA
Voltage - Input (Min) 21.6V
Output Current 104mA
Output Power 1.25W
Max Output Voltage 12V
Nominal Input Voltage 24V
Dimensions
Height 7.62mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
