RM-053.3S/H
RoHS
RoHS compliant
RoHS compliantPackage 4-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 0.25W 05VIN 3.3VOUT
PDF
/
Inventory: 9200
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 10mm
Technical
Nominal Input Voltage 5V
Total Power Output-Max 0.25W
Max Output Voltage 3.3V
Output Power 250mW
Output Current 76mA
Trim/Adjustable Output NO
Input Voltage-Nom 15V
Voltage - Input (Min) 4.5V
Max Output Current 76mA
Output Voltage 3.3V
Voltage - Input (Max) 5.5V
Voltage - Isolation 2kV
Efficiency 70%
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-XSMA-T4
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 250mW
Subcategory Other Analog ICs
Applications ITE (Commercial), Medical
Type Isolated Module
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature SCP
Size / Dimension 0.45Lx0.24W x 0.39 H 11.5mmx6.0mmx10.0mm
Series ECONOLINE RM (0.25W)
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Weight 1.4g
Package / Case 4-SIP Module
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 9 Weeks
