78HT205TC image
Favorite
78HT205TC image
Favorite
RoHS
RoHS RoHS compliant
Package 3-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description REGULATOR 5.00V TOP TAB
PDF
/
Inventory: 8095
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Through Hole
Mounting Type Through Hole
Package / Case 3-SIP Module
Number of Pins 3

Technical

Operating Temperature -40°C~85°C
Packaging Tray
Series 78HT200
Feature OTP, SCP
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Type Non-Isolated PoL Module
Applications ITE (Commercial)
Max Power Dissipation 10W
Terminal Position SINGLE
Terminal Form UNSPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Depth 23.9mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number 78HT205
Pin Count 3
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 82%
Voltage - Input (Max) 28V
Output Voltage 5V
Max Output Current 2A
Voltage - Input (Min) 7V
Input Voltage-Nom 9V
Output Current 2A
Switcher Configuration BUCK
Switching Frequency-Max 800kHz

Dimensions

Length 22.6mm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
