REC3-4812DRW/H2/A/SMD/CTRL
RoHS
RoHS compliant
RoHS compliantPackage 24-SMD Module, 18 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 3W 36-72VIN +/-12VOUT
PDF
/
Buying Options
Total Price: USD $32.82
Unit Price: USD $32.8244
≥1 USD $32.8244
≥10 USD $30.96642
≥100 USD $29.2136
≥500 USD $27.56
≥1000 USD $26
≥3000 USD $24.5283
Inventory: 5434
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 19.9mm
Length 31.8mm
Height 10.9mm
Technical
Nominal Input Voltage 48V
Total Power Output-Max 3W
Voltage - Output 2 -12V
Max Output Voltage 12V
Control Features Enable, Active Low
Output Power 3W
Output Current 125mA
Current - Output (Max) 125mA 125mA
Trim/Adjustable Output NO
Input Voltage-Nom 48V
Voltage - Input (Min) 36V
Max Output Current 125mA
Output Voltage 12V
Voltage - Input (Max) 72V
Voltage - Isolation 2kV
Efficiency 85%
Qualification Status Not Qualified
Number of Outputs 2
JESD-30 Code R-PDMA-G18
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 3W
Subcategory Other Analog ICs
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 18
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Remote On/Off, SCP
Size / Dimension 1.26Lx0.78W x 0.44 H 32.0mmx19.9mmx11.2mm
Series ECONOLINE REC3-DRW (3W)
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Weight 13g
Package / Case 24-SMD Module, 18 Leads
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 9 Weeks
