REC3-1215SRW/H2/A/M/CTRL
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 8 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 3W 9-18VIN 15VOUT
PDF
/
Buying Options
Total Price: USD $15.74
Unit Price: USD $15.735107
≥1 USD $15.735107
Inventory: 2293
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 20.3mm
Length 32mm
Height 10.2mm
Technical
Nominal Input Voltage 12V
Total Power Output-Max 3W
Max Output Voltage 15V
Control Features Enable, Active Low
Output Power 3W
Output Current 200mA
Trim/Adjustable Output NO
Input Voltage-Nom 12V
Voltage - Input (Min) 9V
Max Output Current 200mA
Output Voltage 15V
Voltage - Input (Max) 18V
Voltage - Isolation 2kV
Efficiency 86%
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-MDMA-P9
Terminal Pitch 2.54mm
Number of Functions 1
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 3W
Subcategory Other Analog ICs
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 9
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Remote On/Off, SCP
Size / Dimension 1.26Lx0.80W x 0.40 H 32.0mmx20.3mmx10.2mm
Series ECONOLINE REC3-SRW (3W)
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Weight 13g
Package / Case 24-DIP Module, 8 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 9 Weeks
