EC2SA22NH
RoHS
/
Package 7-SIP Module, 4 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC/DC CONVERTER
PDF
/
Buying Options
Total Price: USD $6.73
Unit Price: USD $6.732
≥1 USD $6.732
≥10 USD $6.63872
≥100 USD $6.54192
≥500 USD $6.349728
≥1000 USD $6.157536
≥3000 USD $5.96508
Inventory: 82
Minimum: 1
-
+
Technical Details
Technical
Current - Output (Max) 167mA
Voltage - Input (Min) 21.6V
Voltage - Output 1 12V
Voltage - Input (Max) 26.4V
Voltage - Isolation 3kV
Efficiency 87%
Number of Outputs 1
Reach Compliance Code compliant
Power (Watts) 2W
Applications ITE (Commercial)
Type Isolated Module
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Size / Dimension 0.77Lx0.28W x 0.40 H 19.6mmx7.2mmx10.2mm
Series EC2SANH (2W)
Operating Temperature -40°C~105°C With Derating
Physical
Package / Case 7-SIP Module, 4 Leads
Mounting Type Through Hole
Supply Chain
Factory Lead Time 8 Weeks
