RBM-0505S/P
RoHS
RoHS compliant
RoHS compliantPackage 6-SIP Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 1W 5VIN 05VOUT
PDF
/
Buying Options
Total Price: USD $7.57
Unit Price: USD $7.57486
≥1 USD $7.57486
≥10 USD $7.1461
≥100 USD $6.7416
≥500 USD $6.36
≥1000 USD $6
≥3000 USD $5.66038
Inventory: 3129
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 7.7mm
Technical
Isolation Isolated
Nominal Input Voltage 5V
Total Power Output-Max 1W
Max Output Voltage 5V
Output Power 1W
Output Current 200mA
Trim/Adjustable Output NO
Input Voltage-Nom 5V
Voltage - Input (Min) 4.5V
Max Output Current 200mA
Output Voltage 5V
Voltage - Input (Max) 5.5V
Voltage - Isolation 3kV
Efficiency 78%
Qualification Status Not Qualified
Number of Outputs 1
Depth 6mm
Number of Functions 1
Terminal Form PIN/PEG
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 1W
Subcategory Other Analog ICs
Applications ITE (Commercial), Medical
Type Isolated Module
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature SCP
Size / Dimension 0.65Lx0.24W x 0.30 H 16.5mmx6.0mmx7.7mm
Series ECONOLINE RBM (1W)
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Weight 1.3g
Number of Pins 5
Package / Case 6-SIP Module, 5 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 9 Weeks
