RB-3.305S/EHP
RoHS
RoHS compliant
RoHS compliantPackage 7-SIP Module, 6 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 1W 3.3VIN 05VOUT
PDF
/
Inventory: 1165
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 7-SIP Module, 6 Leads
Weight 2.2g
Technical
Operating Temperature -40°C~100°C
Packaging Tube
Series ECONOLINE RB/E (1W)
Size / Dimension 0.77Lx0.24W x 0.40 H 19.7mmx6.0mmx10.2mm
Feature SCP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Subcategory Other Analog ICs
Max Power Dissipation 1W
Technology HYBRID
Terminal Position SINGLE
Terminal Form PIN/PEG
Number of Functions 1
Terminal Pitch 2.54mm
JESD-30 Code R-PSMA-P5
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 83%
Voltage - Isolation 2kV
Voltage - Input (Max) 3.63V
Output Voltage 5V
Max Output Current 200mA
Voltage - Input (Min) 2.97V
Input Voltage-Nom 3.3V
Trim/Adjustable Output NO
Output Current 200mA
Output Power 1W
Max Output Voltage 5V
Current - Output 1 200mA
Total Power Output-Max 1W
Nominal Input Voltage (DC) 3.3V
Dimensions
Height 10.2mm
Width 6mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
