R0.5S8-2405-R
RoHS
RoHS compliant
RoHS compliantPackage 8-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
0.5W DC/DC-CONVERTER ECONOLINE
PDF
/
Buying Options
Total Price: USD $18.64
Unit Price: USD $18.639241
≥1 USD $18.639241
≥200 USD $7.437579
≥500 USD $7.18944
≥1000 USD $7.066028
Inventory: 9183
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SMD Module
Weight 1.1g
Technical
Operating Temperature -40°C~100°C
Packaging Tape & Reel (TR)
Series ECONOLINE R0.5S (0.5W)
Size / Dimension 0.50Lx0.42W x 0.28 H 12.8mmx10.7mmx7.0mm
Feature SCP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Subcategory Other Analog ICs
Max Power Dissipation 500mW
Technology HYBRID
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 1
Terminal Pitch 2.54mm
JESD-30 Code R-XDMA-G8
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 75%
Voltage - Isolation 1kV
Voltage - Input (Max) 26.4V
Output Voltage 5V
Max Output Current 100mA
Voltage - Input (Min) 21.6V
Input Voltage-Nom 24V
Trim/Adjustable Output NO
Output Current 100mA
Output Power 500mW
Max Output Voltage 5V
Total Power Output-Max 0.5W
Dimensions
Height 7mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
