SH01D2415A
RoHS
/
Package SMD/SMT
Category Power Supplies - Board Mount / DC DC Converters
Description
PDF
/
Inventory: 9789
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 7.874mm
Length 13.716mm
Height 7.112mm
Technical
Load Regulation-Max(%) 5%
Min Input Voltage (DC) 21.6V
Max Input Voltage (DC) 26.4V
Power - Output 1W
Voltage - Output 3 -15V
Total Power Output-Max 1W
Current - Output 1 67mA
Max Input Voltage 26.4V
Min Input Voltage 21.6V
Voltage - Output 2 -15V
Power Dissipation-Max 1W
Analog IC - Other Type DC-DC REGULATED POWER SUPPLY MODULE
Trim/Adjustable Output NO
Temperature Grade OTHER
Input Voltage-Nom 24V
Voltage - Output 1 15V
Max Output Current 33mA
Output Voltage 15V
Voltage - Isolation 1.5kV
Efficiency 78 %
Number of Outputs 2
JESD-30 Code R-PDMA-G6
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Technology HYBRID
Additional Feature ALSO -15V OUTPUT AVAILABLE
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Number of Terminations 6
Feature SCP
Physical
Package / Case SMD/SMT
Mount Surface Mount
