PYBJ15-Q24-S12-M
RoHS
RoHS compliant
RoHS compliantPackage 15-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC-DC ISOLATED, 15 W, 9-36 VDC I
PDF
/
Buying Options
Total Price: USD $27.32
Unit Price: USD $27.3152
≥1 USD $27.3152
≥10 USD $27.10224
Inventory: 108
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Current - Output (Max) 1.25A
Voltage - Input (Min) 9V
Voltage - Output 1 12V
Voltage - Input (Max) 36V
Voltage - Isolation 1.5kV
Efficiency 89%
Number of Outputs 1
Power (Watts) 15W
Applications ITE (Commercial)
Type Isolated Module
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Remote On/Off, OCP, OVP, SCP
Size / Dimension 1.54Lx1.16W x 0.25 H 39.1mmx29.5mmx6.4mm
Series PYBJ15 (15W)
Operating Temperature -40°C~85°C With Derating
Physical
Package / Case 15-SMD Module
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
Alternative Model
