PDS2-S5-S12-M
RoHS
/
Package 8-SMD Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC-DC ISOLATED, 2 W, 4.5-5.5 VDC
PDF
/
Buying Options
Total Price: USD $7.13
Unit Price: USD $7.128
≥1 USD $7.128
Inventory: 71
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 8.3mm
Height Seated (Max) 7.5mm
Technical
Total Power Output-Max 2W
Current - Output (Max) 167mA
Trim/Adjustable Output NO
Input Voltage-Nom 5V
Voltage - Input (Min) 4.5V
Voltage - Output 1 12V
Output Voltage 12V
Voltage - Input (Max) 5.5V
Voltage - Isolation 1.5kV
Efficiency 82%
Number of Outputs 1
JESD-30 Code R-PDMA-G5
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Technology HYBRID
Power (Watts) 2W
Applications ITE (Commercial)
Type Isolated Module
Number of Terminations 5
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Feature SCP
Size / Dimension 0.50Lx0.33W x 0.29 H 12.7mmx8.3mmx7.3mm
Series PDS2-M (2W)
Published 2016
Operating Temperature -40°C~105°C With Derating
Physical
Surface Mount YES
Package / Case 8-SMD Module, 5 Leads
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 9 Weeks
