PT6722C
RoHS
/
Package 23-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 1.1-1.85V 13A
PDF
/
Inventory: 3826
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 23-SMD Module
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Series Excalibur? PT6722
Size / Dimension 2.58Lx1.19W x 0.50 H 65.5mmx30.2mmx12.7mm
Feature Remote On/Off, OVP, SCP
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 27
ECCN Code EAR99
Type Non-Isolated PoL Module
Applications ITE (Commercial)
Subcategory Switching Regulator or Controllers
Max Power Dissipation 26W
Technology HYBRID
Terminal Position SINGLE
Switching Frequency-Max 400kHz
Switcher Configuration SINGLE
Control Mode VOLTAGE-MODE
Input Voltage-Nom 12V
Voltage - Input (Min) 10.8V
Voltage - Output 1 1.1V~1.85V
Max Output Current 14A
Voltage - Input (Max) 13.2V
Efficiency 83%
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-XSMA-G27
Base Part Number PT6722
Reach Compliance Code unknown
Terminal Pitch 2.54mm
Number of Functions 1
Terminal Form GULL WING
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Height 12.7mm
