THB1448AE
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL 139.7X38MM 48VDC WIRE
PDF
/
Inventory: 7531
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Package / Case Axial
Weight 1.3lbs 589.7g
Material - Frame Aluminum
Material - Blade Plastic
Technical
Published 2011
Series THB
Size / Dimension Square - 139.7mm Lx139.7mm H
Feature Locked Rotor Protection, PWM Control, Speed Sensor (Tach)
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 4 Wire Leads
Power (Watts) 52.8W
Voltage - Rated 48VDC
Max Power Dissipation 52.8W
Reach Compliance Code unknown
Current Rating 1.1A
Approval Agency CE, TUV, UL
RPM 6100 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 325.9 CFM (9.13m3/min)
Noise 66.8 dB(A)
Voltage Range 30V~60VDC
Static Pressure 1.340 in H2O (333.8 Pa)
Dimensions
Height 139.7mm
Compliance
RoHS Status ROHS3 Compliant
