AFB1212HHE
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
DC Fan Axial Ball Bearing 12V 4V to 13.2V 120.07CFM 44dB (120 X 120 X 38mm)
PDF
/
Buying Options
Total Price: USD $18.08
Unit Price: USD $18.084
≥1 USD $18.084
≥10 USD $17.26472
≥100 USD $15.62073
≥500 USD $14.387507
≥1000 USD $12.907567
≥3000 USD $11.921034
Inventory: 120
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 38mm
Height 120mm
Technical
Thermal Support Device Type DC FAN
Static Pressure 0.354 in H2O (88.2 Pa)
Voltage Range 4V~13.2VDC
Noise 44.0 dB(A)
Air Flow 120.1 CFM (3.36m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 2900 RPM
Speed 3500 rpm
Life (Hours) 70000 hours
Lifetime @ Temp 70000 Hrs @ 40°C
Approval Agency CE, CSA, UL, VDE
Current Rating 460mA
Depth 120mm
Max Power Dissipation 5.52W
Current Rating (Amps) 0.460A
Power Rating 5.52W
Voltage - Rated 12VDC
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension Square - 120mm Lx120mm H
Series AFB
Published 2014
Operating Temperature 14~140°F -10°C~60°C
Physical
Material - Frame Plastic
Weight 0.564lb 255.83g
Package / Case Axial
Supply Chain
Factory Lead Time 19 Weeks
Alternative Model
