QFR0812VHE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN 80X80X38MM
PDF
/
Inventory: 8094
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Housing Material Plastic
Material - Frame Plastic
Material - Blade Plastic
Technical
Operating Temperature 14~158°F -10°C~70°C
Series QFR
Size / Dimension Square - 80mm Lx80mm H
Feature Locked Rotor Protection
Part Status Active
Termination 2 Wire Leads
Power (Watts) 3.48W
Voltage - Rated 12VDC
Power Rating 3W
Current Rating (Amps) 0.290A
Approval Agency CE, CSA, UR, VDE
Lifetime @ Temp 70000 Hrs @ 40°C
RPM 5200 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 59.7 CFM (1.67m3/min)
Noise 44.4 dB(A)
Voltage Range 7V~13.2VDC
Static Pressure 0.476 in H2O (118.6 Pa)
Dimensions
Height 80mm
Length 80mm
Width 38.00mm
Compliance
RoHS Status ROHS3 Compliant
