EFB1324SHE-EP
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL 127X38MM 24VDC WIRE
PDF
/
Buying Options
Total Price: USD $70.14
Unit Price: USD $70.1448
≥1 USD $70.1448
≥10 USD $63.46208
≥100 USD $55.11176
≥500 USD $51.77172
≥1000 USD $45.09149
Inventory: 174
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Package / Case Axial
Weight 0.816lb 370.13g
Material - Frame Plastic
Technical
Operating Temperature 14~158°F -10°C~70°C
Published 2010
Series EFB
Size / Dimension Square - 127mm Lx127mm H
Feature GR-487, PWM Control, Speed Sensor (Tach)
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 4 Wire Leads
Voltage - Rated 24VDC
Power Rating 18W
Current Rating (Amps) 0.750A
Max Power Dissipation 18W
Ingress Protection IP56 - Dust Protected, Water Resistant
Reach Compliance Code unknown
Current Rating 750mA
Approval Agency CE, CSA, UL, VDE
Lifetime @ Temp 70000 Hrs @ 40°C
Life (Hours) 70000 hours
RPM 4600 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 200.0 CFM (5.60m3/min)
Noise 58.5 dB(A)
Voltage Range 18V~28VDC
Static Pressure 0.757 in H2O (188.6 Pa)
Dimensions
Height 127mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Ratings IP56, Water Resistant
