PFR1212UHE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN 120X120X38MM
PDF
/
Inventory: 970
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Housing Material Plastic
Material - Frame Plastic
Material - Blade Plastic
Technical
Published 2016
Series PFR
Size / Dimension Square - 120mm Lx120mm H
Part Status Active
Termination 2 Wire Leads
Power (Watts) 32.4W
Voltage - Rated 12VDC
Power Rating 44.4W
Current Rating (Amps) 2.70A
Approval Agency CE, cURus, TUV
RPM 6600 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 228.6 CFM (6.40m3/min)
Noise 65.5 dB(A)
Voltage Range 8V~13.2VDC
Static Pressure 1.206 in H2O (300.4 Pa)
Dimensions
Height 120mm
Length 120mm
Width 38.00mm
Compliance
RoHS Status ROHS3 Compliant
