CFM-6025V-252-312

CUI Devices
RoHS
RoHS RoHS compliant
Package /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description FAN AXIAL 60X25MM 24VDC WIRE
PDF
/
Buying Options
Total Price: USD $6.8
Unit Price: USD $6.8024
≥1 USD $6.8024
≥10 USD $6.49528
≥100 USD $6.108608
≥500 USD $5.876816
≥1000 USD $5.412792
≥3000 USD $5.064822
Inventory: 333
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 22 Weeks

Physical

Weight 0.099lb 44.91g
Material - Frame Polybutylene Terephthalate (PBT)
Material - Blade Polybutylene Terephthalate (PBT)

Technical

Operating Temperature 14~158°F -10°C~70°C
Series CFM-60V
Size / Dimension Square - 60mm Lx60mm H
Feature Auto Restart
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination 2 Wire Leads
Power (Watts) 2.21W
Voltage - Rated 24VDC
Current Rating (Amps) 0.092A
Approval Agency CE, cURus, TUV
Lifetime @ Temp 70000 Hrs @ 40°C
RPM 5200 RPM
Bearing Type omniCOOL? Magnetic Sleeve
Fan Type Tubeaxial
Air Flow 27.0 CFM (0.756m3/min)
Noise 31.2 dB(A)
Voltage Range 8V~27.6VDC
Static Pressure 0.310 in H2O (77.2 Pa)

Dimensions

Width 25.00mm

Compliance

RoHS Status RoHS Compliant
