GFB1212VHW
RoHS
/
Package Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL DUAL 120X76.2MM 12VDC
PDF
/
Inventory: 7549
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case Axial
Weight 1.3lbs 589.7g
Material - Frame Plastic
Technical
Operating Temperature 14~140°F -10°C~60°C
Published 2004
Series GFB
Size / Dimension Square - 120mm Lx120mm H
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Wire Leads per Fan
Additional Feature REAR FAN SPEED: 3200, APPROVALS: UL; VDE
Power Rating 31.8W
Voltage - Rated DC 12V
Max Power Dissipation 31.8W
Reach Compliance Code unknown
Current Rating 2.65A
Approval Agency CE, CSA, UL, VDE
Lifetime @ Temp 70000 Hrs @ 40°C
Life (Hours) 70000 hours
Speed 3550 rpm
RPM 3550 Front, 3200 Rear
Bearing Type Ball
Fan Type Tubeaxial (Dual)
Air Flow 220.3 CFM (6.17m3/min)
Noise 59.0 dB(A)
Voltage Range 7V~13.2VDC
Static Pressure 0.592 in H2O (147.5 Pa)
Thermal Support Device Type DC FAN
Dimensions
Length 120mm
Width 76.2mm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
