PFB0924GHE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL 92X92X38MM 24V WIRE
PDF
/
Buying Options
Total Price: USD $15.17
Unit Price: USD $15.17454
≥1 USD $15.17454
Inventory: 3
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Mount Flanges
Weight 0.551lb 249.93g
Material - Frame Plastic
Technical
Published 2007
Series PFB
Size / Dimension Square - 92mm Lx92mm H
Feature Locked Rotor Protection
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Wire Leads
Voltage - Rated 24VDC
Power Rating 15.12W
Current Rating (Amps) 0.630A
Max Power Dissipation 15.12W
Current Rating 630mA
Approval Agency CE, CSA, UL, VDE
Operating Temperature (Max) 60°C
Operating Temperature (Min) -10°C
RPM 6000 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 129.3 CFM (3.62m3/min)
Noise 60.5 dB(A)
Voltage Range 14V~26.4VDC
Static Pressure 1.015 in H2O (252.8 Pa)
Thermal Support Device Type DC FAN
Life Expectancy 50000 h
Dimensions
Height 92mm
Width 38mm
Compliance
RoHS Status ROHS3 Compliant
