FFB1448UHE-M
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
140X140X38MM 48V DC FAN
PDF
/
Inventory: 2077
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Housing Material Plastic
Material - Frame Aluminum
Material - Blade Plastic
Technical
Operating Temperature 14~158°F -10°C~70°C
Published 2015
Series FFB
Size / Dimension Square - 140mm Lx140mm H
Feature Locked Rotor Protection
Part Status Active
Termination 2 Wire Leads
Power (Watts) 86.4W
Voltage - Rated 48VDC
Power Rating 86.4W
Current Rating (Amps) 1.80A
Approval Agency CE, CSA, UR, VDE
Lifetime @ Temp 80000 Hrs @ 40°C
RPM 5500 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 367.6 CFM (10.29m3/min)
Noise 74.0 dB(A)
Voltage Range 36V~53VDC
Static Pressure 1.644 in H2O (409.5 Pa)
Dimensions
Height 140mm
Length 140mm
Width 38.00mm
Compliance
RoHS Status ROHS3 Compliant
