AFB0512HD
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL 50X20MM 12VDC WIRE
PDF
/
Inventory: 6569
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 50mm
Technical
Static Pressure 0.182 in H2O (45.3 Pa)
Voltage Range 7V~13.8VDC
Noise 33.0 dB(A)
Air Flow 15.8 CFM (0.442m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 5600 RPM
Life (Hours) 70000 hours
Lifetime @ Temp 70000 Hrs @ 40°C
Approval Agency CE, CSA, UL, VDE
Current Rating 100mA
Reach Compliance Code unknown
Depth 50mm
Max Power Dissipation 1.2W
Current Rating (Amps) 0.100A
Power Rating 1.2W
Voltage - Rated 12VDC
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension Square - 50mm Lx50mm H
Series AFB
Published 2002
Operating Temperature 14~158°F -10°C~70°C
Physical
Material - Frame Plastic
Weight 0.084lb 38.1g
Package / Case Axial
Mount Flanges
Supply Chain
Factory Lead Time 19 Weeks
