EFB0612MA image
Favorite
EFB0612MA image
Favorite
RoHS
RoHS RoHS compliant
Package Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description DC Fan Axial Ball Bearing 12V 7V to 13.8V 15.54CFM 29dB( 60 X 60 X 10mm)
PDF
/
Buying Options
Total Price: USD $12.02
Unit Price: USD $12.0208
≥1 USD $12.0208
≥10 USD $11.23584
≥100 USD $10.191104
≥500 USD $9.407024
≥1000 USD $8.231168
≥3000 USD $7.708545
Inventory: 604
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Height 60mm

Technical

Static Pressure 0.094 in H2O (23.4 Pa)
Voltage Range 7V~13.8VDC
Noise 29.0 dB(A)
Air Flow 15.5 CFM (0.434m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 3600 RPM
Cable Length 330mm
Life (Hours) 70000 hours
Lifetime @ Temp 70000 Hrs @ 40°C
Approval Agency CE, CSA, UL, VDE
Current Rating 80mA
Depth 60mm
Max Power Dissipation 960mW
Current Rating (Amps) 0.080A
Power Rating 960mW
Voltage - Rated 12VDC
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension Square - 60mm Lx60mm H
Series EFB
Published 2004
Operating Temperature 14~158°F -10°C~70°C

Physical

Material - Frame Plastic
Weight 0.062lb 28.12g
Package / Case Axial

Supply Chain

Factory Lead Time 19 Weeks
