AFB0912M
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL 92X25.4MM 12VDC WIRE
PDF
/
Buying Options
Total Price: USD $12.22
Unit Price: USD $12.2232
≥1 USD $12.2232
≥10 USD $11.66528
≥100 USD $10.554368
≥500 USD $9.721307
≥1000 USD $8.721354
≥3000 USD $8.054754
Inventory: 543
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 92mm
Technical
Static Pressure 0.130 in H2O (32.4 Pa)
Voltage Range 7V~13.8VDC
Noise 30.0 dB(A)
Air Flow 43.8 CFM (1.23m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 2450 RPM
Life (Hours) 70000 hours
Lifetime @ Temp 70000 Hrs @ 40°C
Approval Agency CE, CSA, UL, VDE
Current Rating 110mA
Reach Compliance Code unknown
Depth 92mm
Max Power Dissipation 1.32W
Current Rating (Amps) 0.110A
Power Rating 1.32W
Voltage - Rated 12VDC
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension Square - 92mm Lx92mm H
Series AFB
Published 2002
Operating Temperature 14~158°F -10°C~70°C
Physical
Material - Frame Plastic
Weight 0.218lb 98.88g
Package / Case Axial
Supply Chain
Factory Lead Time 19 Weeks
