AFB0612HC image
Favorite
AFB0612HC image
Favorite
RoHS
RoHS RoHS compliant
Package Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description FAN AXIAL 60X13MM 12VDC WIRE
PDF
/
Buying Options
Total Price: USD $11.1
Unit Price: USD $11.097001
≥1 USD $11.097001
≥10 USD $10.468861
≥100 USD $9.876292
≥500 USD $9.317251
≥1000 USD $8.789865
Inventory: 1196
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 19 Weeks

Physical

Package / Case Axial
Weight 0.074lb 33.56g
Material - Frame Plastic

Technical

Operating Temperature 14~158°F -10°C~70°C
Published 2002
Series AFB
Size / Dimension Square - 60mm Lx60mm H
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Wire Leads
Voltage - Rated 12VDC
Power Rating 1.68W
Current Rating (Amps) 0.140A
Max Power Dissipation 1.68W
Depth 60mm
Reach Compliance Code unknown
Current Rating 140mA
Approval Agency CE, CSA, UL, VDE
Lifetime @ Temp 70000 Hrs @ 40°C
Life (Hours) 70000 hours
RPM 4200 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 21.2 CFM (0.594m3/min)
Noise 31.5 dB(A)
Voltage Range 7V~13.8VDC
Static Pressure 0.163 in H2O (40.6 Pa)

Dimensions

Height 60mm

Compliance

RoHS Status ROHS3 Compliant
