KFB1724VHT
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
DC Fan Ball Bearing 24V 2.05A 49.2W 3000RPM 289.79CFM 65dB Flange Mount
PDF
/
Inventory: 5435
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 69.00mm
Technical
Static Pressure 1.405 in H2O (350.0 Pa)
Voltage Range 14V~26.4VDC
Noise 65.0 dB(A)
Air Flow 289.5 CFM (8.11m3/min)
Fan Type Motorized Impellers
Bearing Type Ball
RPM 3000 RPM
Operating Supply Voltage 24V
Approval Agency CE, CSA, UR, VDE
Current Rating (Amps) 2.05A
Power Rating 49.2W
Voltage - Rated 24VDC
Power (Watts) 49.2W
Termination 2 Wire Leads
Part Status Active
Size / Dimension Round - 175mm Dia
Series KFB
Physical
Material - Blade Plastic
Material - Frame Aluminum
