AFB0405HHA-AF00
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
40X40X10MM 5V DC FAN W/ SPEED SENSOR (TACH)
PDF
/
Buying Options
Total Price: USD $9.44
Unit Price: USD $9.442621
≥1 USD $9.442621
≥10 USD $8.908135
≥100 USD $8.403903
≥500 USD $7.928208
≥1000 USD $7.479451
Inventory: 1620
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Weight 0.031lb 14.06g
Material - Frame Plastic
Technical
Operating Temperature 14~158°F -10°C~70°C
Published 2014
Series AFB
Size / Dimension Square - 40mm Lx40mm H
Feature Speed Sensor (Tach)
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 3 Wire Leads
Voltage - Rated 5VDC
Power Rating 450mW
Current Rating (Amps) 0.090A
Max Power Dissipation 450mW
Reach Compliance Code unknown
Current Rating 90mA
Approval Agency CE, CSA, UL, VDE
Lifetime @ Temp 70000 Hrs @ 40°C
RPM 7000 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 8.2 CFM (0.230m3/min)
Noise 31.5 dB(A)
Voltage Range 4V~5.5VDC
Static Pressure 0.190 in H2O (47.3 Pa)
Dimensions
Height 40mm
Compliance
RoHS Status ROHS3 Compliant
